Powercom BNT 1000VA Line Interactive UPS

Powercom BNT 1000VA Line Interactive UPS
Powercom BNT 1000VA Line Interactive UPS
The most suitable and the best Quality Protection for Small Servers, and Workstations & PCs. Line interactive design, Boost and buck AVR, Fully digitized microprocessor controlled, Energy saving function, 50/60Hz frequency auto sensing and selection, Cold start function, Lightning and surge protection, Short circuit and overload protection, Advanced battery management, Tel/Modem internet surge suppression
Price:  5,499

Installment Promo! Easy Monthly Payments.

Pay only P 517 a Month for 12 months.

Or pay only P 980 a Month for 6 months.

  • Installment promo is available for locally issued credit cards
  • Card holder must transact inside an Asianic store to avail of the installment

Features

  • Line interactive design
  • Boost and buck AVR (Auto voltage regulation)
  • Fully digitized microprocessor controlled
  • Energy saving function (UPS green mode)
  • 50/60Hz frequency auto sensing and selection
  • Cold start function (DC power on)
  • Lightning and surge protection
  • Short circuit and overload protection
  • Advanced battery management (ABM technology)
  • Tel/Modem internet surge suppression
  • Smart RS-232 communication port *
  • Automatically charging when UPS off
  • History record of power failure events *
  • Back up, on-line, battery status, power status display by software *
  • Schedule shutdown & reboot *


Technical Specifications:

Capacity 1000VA
Output Power Capacity Voltage (on battery) Simulated sine wave at 220V / 230V / 240V +/- 5%
Output Frequency
(on battery)
50 or 60 Hz +/-1Hz
Voltage Regulation
(AVR)
AVR automatically increase output voltage 15% above input voltage if -9% to -25% of nominal.
AVR decrease output voltage 13% below input voltage if +9% to +25% of nominal
Transfer Time 2 / 4 milliseconds, including detection time
Input Voltage 220V / 230V / 240V +/- 25% at line input
Frequency 50 or 60 Hz +/- 10% (auto sensing)
Protection & Filtering Spike Protection 480 Joules, 2ms
Unit Input Fuse for overload & short circuit protection
Overload Protection UPS automatic power off if overload exceeds 110% of nominal at 60 seconds and 130% at 3 seconds
Short Circuit UPS output cut off immediately or input fuse protection
Battery Type Sealed, maintenance-free lead acid batteries with 3-6 years typical lifetime
Typical Recharge Time 6 hours (to 90% of full capacity)
Back-up Time
(a PC with 15" monitor)
35 - 45 minutes
Protection Auto discharge protection
Physical Net Weight kg (lbs) 8.0 (17.2)
Shipping Weight Kg (Ibs) 8.5 (18.3)
Dimension WxDxH (mm) 97 x 320 x 135
(3.8" x 12.5" x 5.3")
Input Inlet IEC 320 power inlet
Receptacles IEC 320 female appliance coupler (220V)
Interface RS232
Alarm Battery Back-up Slow beeping sound
(about 0.47 Hz)
Battery Low Rapid beeping sound
(about 1.824 Hz)
Overload Continuously beeping sound
Environment Ambient Operation 3,500 meters max, elevation. 0-95% humidity non-condensing, 0-40 deg
Audible Noise <40dBA (1 meter from surface)
Storage Condition 15,000 meter max. elevation
