Across LC90SA 90W with USB Charging Universal AC Adapter

Across LC90SA 90W with USB Charging Universal AC Adapter

Across 90W Universal AC Adapter, USB Charging Port Included, Slim,easy carry, Wide Operating Voltage 90~240Vac, Output Voltage: 15-24V, OCP,OPP,SCP,OTP, Size:123(L)x60(W)x18(H)mm. Superior Quality and Design. Heavy Duty and Reliability.

Availability: Phased Out

Features

Technical Specifications

Input Spec.

Input Voltage Range:	90 ~ 240Vac
Input Frequency Range:	47 ~ 63 Hz
Input Current:	1.6A
No Load Operation:	< 0.5W
Efficiency :	88% @ 230Vac typical load

Output Spec.

Output Voltage	Load (Min)	Range(Max)	Regulation (V)	Rated Power (W)
15V	0A	4.50A	14.5V ~ 15.5V	68W
16V	0A	4.50A	15.5V ~ 16.5V	72W
18V	0A	4.50A	17.5V ~ 18.5V	81W
18.5V	0A	4.50A	18.0V ~ 19.0V	83W
19V	0A	4.50A	18.5V ~ 19.5V	86W
19.5V	0A	4.50A	19.0V ~ 20.0V	88W
20V	0A	4.50A	19.5V ~ 20.5V	90W
22V	0A	3.75A	21.5V ~ 22.5V	83W
24V	0A	3.75A	23.5V ~ 24.5V	90W
